GIRA
057600
Landed Cost
Product code:
0576 00
Brightness sensor for detection and analysis of the brightness. The brightness sensor can be operated in conjunction with the basis weather station or the analogue sensor interface. The required power supply (24 V DC) is provided by these devices. Connection to systems from other manufacturers is also possible.
Description
The device is suitable for outdoor installation and is equipped to prevent the build-up of moisture with a pressure-compensation element ("climate membrane").
The detected brightness is converted to a linear, analogue output signal from 0 to 10 V.
Technical Details
Specification
- Measurement range: 0 to 60000 lux, linear
- Electrical output: 0 to 10 V DC (short-circuit-proof)
- External supply
- Voltage: 24 V DC
- Current consumption: approx. 5 mA
- Ambient temperature: -30 °C to +70 °C
- Cable length: max. 100 m
- Recommended cable: 3 x 0.25 mm_
- Dimensions: W x H x D 90 x 58 x 35 mm
- Installation location: any
- Protection type: IP 65
- Instabus weather station comfort 1010 00
- Instabus analogue sensor interface 1021 00
- Mounting bracket 1406 00
Properties
Properties
| Technology | KNX |
| Brand | GIRA |
| Insert finish | White |
| IP rating | IP40 |
| EAN | 4010340000000 |
